H-PRD-4E

　　HIGH PERFORMANCE END OF LINE PRESSURE RELIEF DEVICES

　　壓力釋放閥

　　Key Features

　　GFI’s pressure relief devices are designed for maximum heat transfer and fast activation performance reliability. The high flow discharge design provides the security of knowing that in the unlikely event that it is required to activate, it will ensure that the safety of the CNG/CHG system remains intact. Offered with a wide range of options, these devicescan be configured to meet the requirements of your application.

　　? Combined T-PRD and P-PRD (Burst disk) pipe away port

　　? High flow, fast acting design

　　? Glass bulb or cadmium free eutectic technology

　　? Nominal working pressure 35 MPa

　　? Working temperature -40° to +85° C

　　? Wide range of port options 3/4-16, 9/16-18, 7/16-20

　　or M18x1.5 to M16x1.5

　　? Light weight machined aluminum body

　　主要特性

　　公司的GFI氫氣壓力釋放閥系列產品時最大化了熱量交換的速度，所以響應快、流量大。當需要壓力釋放閥工作時氣體可以很快的釋放，從而保證CNG/CHC系統的安全。本產品接頭規格很全，可以根據客戶的要求進行定制。

　　? 集成溫度型和壓力型釋放閥，二者共用一個泄壓通道;

　　? 流量大，響應快;

　　? 溫控玻璃管或者非鎘易熔合金技術;

　　? 最大工作壓力35MPa;

　　? 工作溫度范圍-40℃ to 85℃;

　　? 可供選擇借口尺寸：3/4-16，9/16-18，7/16-20, M18x1.5 to M16x1.5;

　　? 輕量化鋁制機體。
